| TECHNICAL SPECIFICATIONS:- |
|
| PULLING CAPACITY |
2000 kgf to 10000 kgf. [And More on Special Req.] |
| PULLING SPEED |
0.04 Meter/Min. to 1.8 Meter/Min. |
| DIE CLAMPING BED |
1000mm X 1100mm |
| MOVING PULLER SIZE |
600 X 600 to 1000 X 650mm [2 Nos.] |
| GRIPPING |
By Vertical Moving Single or Double Platen Clamping System |
| CARRIAGE MOVEMENT |
By Hydraulic Power. |
| CLAMPING FORCE |
By Hydraulic Actuating System |
| HEATING ZONE |
3 – 9 , Depending upon no. of Grippers |
| ELECTRICAL POWER REQUIRED |
2.0 to 7.5 Kw for Hydraulic Power Pack
Heating Requirement (Depending up on Size of mould) |
| COLLING WATER REQUIRED |
40 lpm @ 26 – 28 C˚ [ form cooling tower ] |
| ACCESSORIES |
Glass Roving (Creel) Stands, Roving Guides, Perform Guides, Resin Impregnation Bath, Resin Pressure Injection System, Glass Mat Roll Feeding Station, Automatic Section Cutter, Section conveying Roller Table, Glass Mat Slitter & Pultrusion Mold, |
| Approximately Overall Dimensions |
Length |
Width |
Height |
| |
6500 – 8000mm |
1000mm |
2000mm |
